S11 Yellow/Green Heat Shrink Tube


Introduction
A flexible,flame-retardant polyolefin,yellow/green striped color. Instant identification of "ground" on wires and cables.
Features
Operating temperature: -40 to 125°C
Minimum full recovery temperature: 125°C
Shrink ratio: 2:1 & 3:1
Environmental friendly, RoHS compliant, Flame-retardant
Standard Color: Yellow/Green(-45)
Co-extrusion of Green/Yellow striped color
Technical Data
Property Test Method Requirement
Tensile Strength ASTM D2671 ≥10.4 MPa
Ultimate Elongation ASTM D2671 ≥200%
"Heat Aging (158°C/168h)
Tensile Strength
Ultimate Elongation" ASTM D2671 "
≥7.3 MPa
≥100%"
Water absorption (23°C/24h) ASTM D2671 ≤0.5%
Low-temperature flexibility (-40°C/4h) ASTM D2671 No cracking
Heat shock (225°C/4h) ASTM D2671 No cracking, dripping or flowing
Dielectric breakdown ASTM D2671 ≥AC 2500V
Dielectric withstand at 2500 V ASTM D2671 ≥60s
Volume resistivity ASTM D2671 ≥1.0×1014Ω.cm
Flammability ASTM D2671 method C Self-extinguishing within 60S
Copper corrosion (158°C/16h) ASTM D2671 No corrosion
Dimension
Size As supplied(mm) After recovered (mm) "Standard length
(m)"
S11 "Inner diameter
D (min.)" "Inner diameter
d (max.)" "Wall thickness
t (nom.)"
Shrink ratio 2:1
1.0 1.0 0.7 0.28 200
2.0 2.0 1.0 0.35 200
3.0 3.0 1.5 0.38 200
4.0 4.0 2.0 0.45 200
5.0 5.0 2.5 0.45 100
6 6.0 3.0 0.50 100
7 7.0 3.5 0.50 100
8 8.0 4.0 0.55 100
9 9.0 4.5 0.55 100
10 10.0 5.0 0.55 100
12 12.0 6.0 0.60 100
14 14.0 7.0 0.60 100
16 16.0 8.0 0.70 100
18 18.0 9.0 0.70 100
20 20.0 10.0 0.80 100
25 25.0 12.5 0.90 50
30 30.0 15.0 0.95 50
35 35.0 17.5 1.00 50
40 40.0 20.0 1.00 50
50 50 25 1.00 25
60 60 30 1.10 25
70 70 35 1.20 25
80 80 40 1.30 25
90 90 45 1.50 25
100 100 50 1.70 25
Shrink ratio 3:1
3/1 3.0 1.0 0.55 200
4.5/1.5 4.5 1.5 0.60 100
6/2 6.0 2.0 0.65 100
9/3 9.0 3.0 0.75 50
12/4 12.0 4.0 0.75 50
18/6 18.0 6.0 0.85 50
24/8 24.0 8.0 1.00 25
39/13 39.0 13.0 1.50 25
Shrink ratio 3:1 (adhesive linner)
12/4 12.0 4.0 -- 1.22
18/6 18.0 6.0 -- 1.22
24/8 24.0 8.0 -- 1.22
39/13 39.0 13.0 -- 1.22
Cross Reference
Tyco-Raychem: DCPT
